Our Products

Leading Edge Mixed-Signal IC Technology for Automotive, Robotics, and Industrial Applications

Microcontroller Solutions

Microcontroller (MCU) Products

Xscend's microcontroller products are engineered for critical motion and motor control applications where space is a premium. Delivering strong processing power in a compact package, Xscend MPUs are designed to support complex motion and motor control algorithms for rapid and accurate movement in autonomous and robotic systems. They fuse advanced computation with sensing, PMIC and motor drive functions. The ideal solution for next-generation robotics and smart vehicles.

Key Benefits

  • High Integration: Combines motion control logic with peripheral interfaces, reducing system complexity and accelerating development timelines.
  • Real-Time Precision: Processes data with ultra-low latency for accurate motor synchronization and adaptive control.
  • Energy Efficiency: Optimizes power usage for battery-powered applications, extending operational life in robotics and EVs.
  • Scalable Performance: Supports advanced AI algorithms for complex motion, future-proofing designs in an ever evolving tech landscape.
MCU Product Brief

Quick Specs

  • Single chip motor control solution
  • Arm-based controller with up to 256KB on-chip Flash
  • Integrated PMIC, Communication PHY and Driver
  • Small package / High integration lead to smaller board footprint
  • Up to 40V input power
Robotic assembly line with precision circuit board manufacturing

XT32F204/5x Series — LIN Transceiver + MOSFET Driver

Single-chip real-time MCU with integrated LIN 2.2 transceiver and 2/3-phase MOSFET driver. QFN-48 (7x7mm), 4KV ESD, ASIL-B ready.

Product Core Freq Flash (KB) SRAM (KB) ROM (KB) LIN PHY 3-ph Driver 2-ph Driver Tj max (°C)
XT32F2044 40 MHz 64 4 24 1 0 1 150
XT32F2045 40 MHz 128 4 24 1 0 1 150
XT32F2048 40 MHz 64 4 24 1 0 1 175
XT32F2049 40 MHz 128 4 24 1 0 1 175
XT32F2054 40 MHz 64 4 24 1 1 0 150
XT32F2055 40 MHz 128 4 24 1 1 0 150
XT32F2058 40 MHz 64 4 24 1 1 0 175
XT32F2059 40 MHz 128 4 24 1 1 0 175

XT32F208/9x Series — CAN FD Transceiver + MOSFET Driver

Single-chip real-time MCU with integrated CAN FD transceiver, 12-bit + 14-bit Sigma Delta ADC, and 2/3-phase MOSFET driver. QFN-48 (7x7mm), 4KV ESD, ASIL-B ready.

Product Core Freq Flash (KB) SRAM (KB) ROM (KB) CAN FD 3-ph Driver 2-ph Driver Tj max (°C)
XT32F2084 40 MHz 128 16 32 1 0 1 150
XT32F2085 60 MHz 256 32 32 1 0 1 150
XT32F2088 40 MHz 128 16 32 1 0 1 175
XT32F2089 60 MHz 256 32 32 1 0 1 175
XT32F2094 40 MHz 128 16 32 1 1 0 150
XT32F2095 60 MHz 256 32 32 1 1 0 150
XT32F2098 40 MHz 128 16 32 1 1 0 175
XT32F2099 60 MHz 256 32 32 1 1 0 175
SerDes Solutions

MIPI SerDes Products

Xscend's MIPI A-PHY line delivers open-protocol, high-speed interfaces up to 8Gbps per channel over a single twisted pair, revolutionizing data communication in automotive and robotics ecosystems. These SerDes solutions bridge MIPI CSI-2 and DSI-2.1 interfaces to the A-PHY standard using PAM4 and other coding schemes, enabling reliable connectivity across up to 15 meters via shielded differential pair (SDP) or coaxial wiring -- with support for power over cable. Featuring flexible streaming, synchronization, and pin compatibility with existing standards, they provide seamless, low-latency links for cameras, sensors, and processors. Ideal for drones, railways, ADAS, and single-chip integrations.

Key Benefits

  • Ultra-Fast Transmission: Delivers gigabit speeds for handling large data volumes without bottlenecks.
  • Flexible Compatibility: Open protocol and pin-compatibility simplify upgrades and integrations.
  • Reliable Performance: Built-in synchronization and protection for uninterrupted operation in dynamic environments.
  • Cost-Effective Scalability: Reduces complexity in multi-device setups, lowering overall system costs.
SerDes Product Brief

Quick Specs

  • Up to 8Gbps per channel bandwidth
  • MIPI A-PHY compliant (CSI-2 / DSI-2.1)
  • PAM4 encoding for maximum throughput
  • Up to 15m reach over twisted pair or coax
  • Power over cable support
  • Pin compatible with incumbent SerDes
  • ASIL-B compliant
Automotive ADAS camera sensor system on vehicle windshield

Camera SerDes Bridge Chips — XTL96xx Series

MIPI A-PHY compliant camera serializer/deserializer ICs bridging CSI-2 interfaces for ADAS, drone, railway, and robotics applications.

Part # Type Protocol Video IF Bandwidth
XTL9643 Deserialize 2xAPHY G3 2xCSI 2 4x8Gbps
XTL9642 Deserialize 2xAPHY G2 2xCSI 2 4x4Gbps
XTL9623 Deserialize 2xAPHY G3 CSI 2 2x8Gbps
XTL9622 Deserialize 2xAPHY G2 2xCSI 2 2x4Gbps
XTL9613 Serialize APHY G3 CSI 2 8Gbps
XTL9612 Serialize APHY G2 CSI 2 4Gbps

Display SerDes Bridge Chips — XTL85xx Series

MIPI A-PHY compliant display serializer/deserializer ICs bridging DSI-2.1 interfaces for automotive infotainment and industrial display applications.

Part # Type Protocol Video IF Bandwidth
XTL8513 Serialize 2xAPHY G3 2xDSI 2.1 8Gbps
XTL8512 Serialize 2xAPHY G2 2xDSI 2.1 4Gbps
XTL8523 Deserialize APHY G3 DSI 2.1 8Gbps
XTL8522 Deserialize APHY G2 DSI 2.1 4Gbps
Sensor Solutions

Sensor Products

Xscend sensor products deliver high-precision measurement and monitoring capabilities for a wide range of applications. Designed with advanced resistive and capacitive sensing technologies, they support input sensitivities as low as 10mV and operating voltages from 2.7V to 40V. Offering both analog and digital output options, these sensors ensure seamless integration into diverse systems, delivering ultra-fast response times (<1ms) and exceptional accuracy, up to 0.05% with 20-bit ADCs. Equipped with robust diagnostics, including reverse polarity protection (RPP) and low-dropout features.

Key Benefits

  • Dual Sensing Capability: Supports both voltage and current sensing with high linearity, ensuring precise and consistent measurements across diverse conditions.
  • Robust Reliability: Low drift and fast response times maintain performance in harsh, variable environments.
  • Seamless Integration: Designed for easy embedding into broader chip architectures, minimizing design overhead.
  • Versatile Applications: Ideal for automotive, industrial, and energy sectors, enhancing data-driven intelligence.
Sensor Product Brief

Quick Specs

  • Input sensitivity as low as 10mV
  • Operating voltage: 2.7V to 40V
  • Ultra-fast response: <1ms
  • Up to 0.05% accuracy with 20-bit ADC
  • DIO, I2C, SPI interfaces
Industrial flow meter sensor with precision digital display

Sensor Product Line — XPS3xxx Series

Resistive and capacitive sensor ICs for automotive pressure, BMS current sensing, and industrial/medical applications.

Part # Sensor Type Voltage Input Output Response Accuracy Interface Diagnosis
XPS3500 Resistive 2.7-5.5V >10mV Voltage <1ms 0.6% 12b DAC DIO Connect
XPS3501 Resistive 3-40V >25uV Voltage <1ms 0.1% 20b ADC DIO, I2C Connect
XPS3502 Capacitive 3-40V >25uV Voltage <1ms 0.1% 20b ADC DIO, I2C Connect
XPS3505 Resistive 3-40V >25uV Voltage <1ms 0.1% 20b ADC DIO, I2C Connect, RPP
XPS3506 Capacitive 3-40V >25uV Voltage <1ms 0.1% 20b ADC DIO, I2C Connect, RPP
XPS3601 Capacitive 3-40V >25uV Current <1ms 0.05% 20b ADC DIO, I2C/SPI Connect, RPP
XPS3602 Capacitive 3-40V >25uV Current <1ms 0.05% 20b ADC DIO, I2C/SPI Connect, RPP
Driver Solutions

Gate Driver Products

The Xscend gate drivers, designed for high-voltage half-bridge and single-channel applications, offer robust features tailored for automotive and industrial use, such as motor control, renewable energy systems, and EV battery chargers. They support a wide range of power devices (MOSFETs, IGBTs, SiCs) with output voltages up to 1700V and drive current capabilities from 0.35/0.65A to 14A. Key features include fast switching with Ton/Toff times as low as 200ns, comprehensive protection mechanisms, and enhanced reliability through iso-ring and capacitance isolation (up to 5.7kV Vrms).

Key Benefits

  • Strong Isolation and Speed: Quick response times with robust protection for safe, high-voltage operations.
  • Efficiency Optimization: Low standby current and high accuracy minimize energy loss and enhance performance.
  • Integrated Simplicity: Reduces component count and BOM costs in complex systems.
  • Broad Application Fit: Tailored for automotive, robotics, and energy sectors requiring reliable high-voltage handling.
Driver Product Brief

Quick Specs

  • Output voltage up to 1700V
  • Drive current: 0.35A to 14A
  • Ton/Toff as low as 200ns
  • Isolation up to 5.7kV Vrms
  • MOSFET, IGBT, SiC compatible
Electric vehicle charging interface display showing battery status

Half-Bridge Solutions — XTD10xx Series

High-voltage half-bridge gate drivers with iso-ring and OCP protection for motor control, battery chargers, and energy storage systems.

Part Peak Current (A) Dead Time Vin (V) Vout (V) Device Ton/Toff (ns) Features Package
XTD1000 1.7/2.2 Adjustable 10-20 900 IGBT 670/270 - SOIC-14
XTD1001 1.7/2.2 Fixed 10-20 900 IGBT 350 Cross interlocking PG-DSO-16
XTD1011 1.7/2.2 Fixed 10-20 800 IGBT 250 Cross interlock, Bootstrap, Miller Clamp PG-DSO-16
XTD1027 1.7/2.2 Fixed 10-20 1200 IGBT 350 Cross interlocking PG-DSO-16

Single Channel & Three-Phase Solutions

High-voltage single channel and three-phase gate drivers supporting up to 1700V with cap-iso and iso-ring isolation for industrial motor drives and EV applications.

Part Peak Current (A) Dead Time Vin (V) Vout (V) Device Ton/Toff (ns) Isolation Features Package
XTD1005 1.7/2.2 Fixed - 900 IGBT 350 Iso-Ring - SOP8
XTD2000 4 Adjustable 10-20 1700 IGBT/SiC 200 Cap-Iso Miller Clamp, Neg Voltage Bias PG-DSO16-15
XTD3000 10 Adjustable 10-20 1700 IGBT/SiC 200 Cap-Iso Miller Clamp, Neg Voltage Bias PG-DSO16-15
XTD1031 0.35/0.65 Fixed 10-20 800 IGBT/SiC 250 Iso-Ring Bootstrap Diode, Gate Resistor DSO-24
PMIC Solutions

Power Management IC (PMIC) Products

Xscend LDO (Low Dropout) regulator products are high-precision, low-noise power management solutions designed to deliver stable and efficient voltage regulation for sensitive applications. With support for input voltages up to 40V and ultra-low dropout performance, these regulators ensure consistent operation even under varying input conditions. Featuring exceptional output accuracy, low quiescent current, and advanced thermal protection, Xscend LDO regulators are ideal for powering noise-sensitive analog and RF circuits.

Key Benefits

  • High Efficiency: Maximizes power conversion to minimize waste, ideal for battery-dependent systems.
  • Compact Design: Low BOM and small footprint streamline integration without sacrificing capability.
  • Advanced Protection: Robust features guard against faults, enhancing system longevity and safety.
  • Scalable for Future Tech: Ready for emerging platforms like ADAS and 48V architectures, ensuring long-term viability.
PMIC Product Brief

Quick Specs

  • Input voltage support up to 40V
  • Ultra-low dropout performance
  • Low quiescent current (<50uA / 5uA ultra-low)
  • Advanced thermal protection
  • Reverse polarity protection (RPP)
  • AEC-Q100 Grade 1 qualified
Electric vehicle powertrain cutaway showing motor windings and power electronics

LDO Regulators — XTM1xx Series

High-precision, low-noise LDO regulators with ±1% output accuracy, 4kV ESD tolerance, and AEC-Q100 Grade 1 qualification for automotive ECU, sensor, and industrial power supply applications.

LDO Family Vin Vout Iq Package Notes
XTM113xx 5.5 - 40V Adj, 1.6V, 1.8V, 2.5V, 3.0V, 3.3V, 5.0V 50 uA SOT-23 ±1% accuracy, 300mA max
XTM100x 5.5 - 40V 5V 50 uA TO-252-5 / PG-DSO-8 ±1% accuracy, 300mA max
XTM101x 5.5 - 40V Adjustable Varies ETSSOP P-16 ±1% accuracy, Iout varies
XTM103x 2.2 - 6V Adjustable 50 uA SOT-223 ±1% accuracy, 1A / 0.5A max
XTM104x 3 - 40V Adjustable 5 uA TO-252-5 ±1% accuracy, 300mA max

DC-DC Buck & Buck/Boost Converters — XPM2xx Series

High-efficiency DC-DC converters with >90% efficiency, wide input voltage range, and comprehensive OCP/OTP protection for automotive SOC, IVI, and SerDes power supply applications.

Part Type Max Freq (MHz) Standby (uA) Output (A) Vin (V) Compatible Package
XPM2002 Buck 2.5 60 3 2.7-6 MPQ2166 QFN-18
XPM2001 Buck 2.5 60 2 2.7-6 MPQ2166 QFN-18
XPM2000 Buck 2.5 60 1 2.7-6 MPQ2166 QFN-18
XPM2012 Buck 2.5 60 3 3.8-36 LMR33630 HSOIC-8
XPM2011 Buck 2.5 60 2 3.8-36 LMR33630 HSOIC-8
XPM2010 Buck 2.5 60 1 3.8-36 LMR33630 HSOIC-8
XPM2021 Buck/Boost 2.5 60 1.2 2-36 MAX20040 SWTQFN-20
XPM2020 Buck/Boost 2.5 60 0.6 2-36 MAX20039 SWTQFN-20
